Microconnect MC-UTP6A01W Cable de red blanco 1 m Cat6a U/UTP (UTP)

The MicroConnect CAT6a Patch Cable MC-UTP6A01W is a 1 m networking cable designed for environments that require 10 Gbit/s performance and wide bandwidth. The U/UTP unshielded design and gold-plated contacts in the RJ-45 connectors provide reliable signal transmission, while meter markings on the boot and latch protection improve handling and durability.

Advantages

This Cat6a cable supports data transfer rates up to 10000 Mbit/s and bandwidth up to 500 MHz. The connectors feature 50 μ" gold plating for improved contact quality, and the latch protection reduces the risk of clip breakage during installation and maintenance. The white jacket and 1 m length suit short-range patching in racks, switches and patch panels.

Suitable for

• 10G Ethernet connections between switches and servers
• Patch panel to switch cabling in data cabinets
• High-bandwidth workstations and networked storage
• Short-distance horizontal cabling within server rooms

Key specifications

• Standard: Cat6a (IEEE-compatible)
• Data rate: up to 10000 Mbit/s
• Bandwidth: up to 500 MHz
• Length: 1 m
• Connectors: RJ-45 — RJ-45 with gold-plated contacts (50 μ" plating)
• Shielding: U/UTP (unshielded twisted pair)
• Color: White
• Weight: 0.04 kg

How to use

Connect one RJ-45 connector to the network port on your device or patch panel and the other to the corresponding switch, router or server port. Ensure connectors click into place and that latch protection is not obstructed. Use meter markings on the boot to verify cable length when planning or routing in racks and cabinets.

Recommendations

For optimal performance, avoid sharp bends and excessive tension on the cable, maintain separation from strong electromagnetic sources, and use for short-distance patching up to 1 m as intended by the product specifications.
