MITAC CYPRISER3RTM tarjeta riser PCIe Gen3 x16 para 1U/2U M50CYP Slot 3 con 2x SFF-8643 NVMe

PCIe riser card engineered to unlock high-speed NVMe storage connectivity in Gigabyte M501-G20 series servers. This low-profile card plugs into PCIe x16 Slot 3 and delivers two SFF-8643 Mini-SAS HD ports, enabling direct PCIe lanes to NVMe backplanes for up to eight U.2 drives. Built for 1U and 2U rack environments, it provides a reliable, plug-and-play pathway to maximize storage performance without compromising space or airflow.

Advantages

The CYPRISER3RTM transforms a standard PCIe slot into a high-bandwidth NVMe expansion point. Its Gen3 x16 interface ensures full throughput for demanding data-intensive applications, while the dual SFF-8643 connectors offer flexible cabling to compatible backplanes. The low-profile design fits seamlessly into dense server chassis, and PCIe slot power eliminates extra cabling. High-quality PCB construction guarantees stable signal integrity and long-term reliability in 24/7 operation.

Suitable for

• Gigabyte M501-G20 series servers requiring additional NVMe storage capacity
• Data centers and enterprises deploying high-performance U.2 NVMe SSDs
• IT administrators upgrading existing servers with minimal downtime
• 1U and 2U rack server builds where space is at a premium
• Applications demanding low-latency storage access: databases, virtualization, AI/ML workloads

Key specifications

• Product type: PCIe riser card
• Server compatibility: Gigabyte M501-G20 series
• Motherboard slot: PCIe x16 Slot 3
• PCIe generation: Gen3
• PCIe lanes: x16
• NVMe support: Yes, provides PCIe lanes for NVMe backplane
• Output connectors: 2x SFF-8643 (Mini-SAS HD)
• Supported NVMe drives: Up to 8 NVMe U.2 drives (via compatible backplane/cables)
• Form factor: Low profile, designed for 1U/2U rack servers
• Power source: PCIe slot power
• Material: High-quality PCB
• Installation: Plug-and-play within compatible system
• Operating temperature range: 0°C to 55°C
• Operating humidity range: 10% to 90% non-condensing

Recommendations

Pair this riser with a compatible NVMe backplane and high-quality SFF-8643 cables to achieve optimal signal integrity and drive performance. Verify server BIOS and firmware support for PCIe bifurcation if required. For best results, install in a well-ventilated chassis to maintain operating temperature within specified limits.
