MITON MT-P1280-S Caja exterior hermética ABS IP65 128x80x55mm gris claro

The MITON MT-P1280-S is a high-quality hermetic outdoor enclosure designed to protect small electronic devices, network equipment, and IoT sensors in harsh environments. Manufactured from UV-stabilized ABS plastic with an IP65 rating, it offers reliable protection against dust and water jets. The enclosure features a light grey colour, wall/pole mountable design, and includes a silicone gasket for a secure seal.

Advantages

Robust IP65 protection ensures durability outdoors. UV-stabilized material prevents degradation from sunlight. Compact size with internal standoffs for easy PCB mounting. Cable entry points for PG9 glands simplify wiring.

Suitable for

• Outdoor electronic projects
• Network equipment protection
• IoT sensor housings
• Small device enclosures

Key specifications

• Enclosure Type: Hermetic Outdoor
• Material: ABS Plastic
• IP Rating: IP65
• External Dimensions (L x W x H): 128 x 80 x 55 mm
• Internal Dimensions (L x W x H): 120 x 75 x 50 mm
• Colour: Light Grey
• Mounting Type: Wall/Pole Mountable
• Lid Fastening: 4x Screws
• Seal Type: Silicone Gasket
• Cable Entry Points: 2 (for PG9 glands)
• UV Resistance: Yes, UV Stabilized
• Operating Temperature Range: -20°C to +70°C
• Internal Mounting Features: Standoffs for PCB

Recommendations

For best results, use appropriate PG9 cable glands and ensure the silicone gasket is properly seated before closing the lid. Suitable for outdoor installations where dust and water protection is required.
