MITON MT-P130-B Caja de derivación de superficie IP65 gris ABS

The MITON MT-P130-B is a robust surface-mounted junction box designed for indoor and outdoor electrical installations. Manufactured from high-quality ABS plastic with a grey (RAL 7035) finish, this IP65-rated enclosure provides excellent protection against dust and water jets, making it suitable for demanding environments. The box features an opaque screw-on lid with an EPDM gasket, ensuring a secure and weatherproof seal. Its smooth walls allow for custom cable entry via drilling or glands, while external mounting lugs facilitate easy installation.

Advantages

This junction box offers exceptional durability and flexibility. The UV-resistant and halogen-free ABS material ensures long-term performance in outdoor conditions. The IP65 rating guarantees protection against dust ingress and low-pressure water jets, while the IK07 impact resistance safeguards against mechanical shocks. The internal bosses accommodate mounting plates or DIN rails, providing versatile mounting options for various components.

Suitable for

• Electrical junction and connection points in industrial, commercial, and residential settings
• Outdoor installations such as gardens, terraces, and building exteriors
• Enclosures for network outlets, consolidation points, or fibre/FTTH boxes
• Custom cable management and termination applications

Key specifications

• Enclosure Type: Surface-Mounted Junction Box
• IP Rating: IP65
• External Dimensions (L x W x H): 130 x 130 x 70 mm
• Internal Depth: Approx. 65 mm
• Material: ABS Plastic
• Colour: Grey (RAL 7035)
• Lid Type: Opaque, Screw-on
• Seal Material: EPDM Gasket
• Cable Entry: Smooth walls for custom drilling/glands (no pre-drilled holes)
• Impact Resistance: IK07
• Operating Temperature: -25°C to +60°C
• Flammability Rating: UL94-V2
• UV Resistance: Yes
• Halogen-Free: Yes
• Internal Mounting: Bosses for mounting plate/DIN rail
• Mounting Type: External mounting lugs
• Standards Compliance: EN 60670-1, EN 60670-22
• Application Environment: Indoor and Outdoor

Recommendations

For optimal performance, use appropriate cable glands for entry points and ensure the lid is properly tightened to maintain the IP65 seal. This box is ideal for custom installations where pre-drilled entries are not required.
