Módem USB-C TELTONIKA Trm500 5G

The Teltonika TRM500 is a compact 5G modem designed for high-speed mobile connectivity. Featuring an internal antenna, USB Type-C connectivity and LED indicators for network and power status, the TRM500 supports peak cellular speeds up to 3.4 Gbps and remains compatible with 4G (Cat 19) and 3G networks. Its small footprint (83 mm depth, 25 mm height) and light weight (94.5 g) make it suitable for space-constrained installations where reliable 5G access is required.

Advantages

The TRM500 provides ultra-high cellular throughput up to 3.4 Gbps while maintaining backward compatibility with 4G and 3G. Its internal antenna and compact form factor reduce external cabling and simplify mounting options. The device includes a USB Type-C port that supports simultaneous data and power, and clear LED indicators help monitor network and power status at a glance.

Suitable for

• Mobile and temporary 5G internet access
• Compact or space-limited installations
• Industrial and commercial edge connectivity where small form factor is required

Key specifications

• Cellular: 5G with backward compatibility for 4G (Cat 19) and 3G
• Peak speed: up to 3.4 Gbps
• Antenna: Internal
• Interfaces: USB Type-C (data and power)
• Mounting: DIN rail options
• Weight: 0.0945 kg
• Dimensions (depth × height): 83 mm × 25 mm
• Colour: Black

How to use

Connect the TRM500 to a compatible host or power source using the USB Type-C port. Place the unit where cellular signal strength is optimal, ensuring the internal antenna has minimal obstruction. Use the LED indicators to verify power and network registration. For DIN rail installations, secure the modem to the rail according to the mounting instructions supplied by the manufacturer.

Recommendations

Place the TRM500 in a location with clear reception, avoid metal enclosures that can block signal, and use a stable power source via the USB Type-C interface. For critical applications, verify network compatibility and test throughput on-site before permanent installation.
