Módulo de memoria RAM para portátil ADATA AD5S560048G-S 48 GB DDR5 5600 MT/s 262-Pin SO-DIMM CAS46 1,1 V negro

ADATA AD5S560048G-S is a 48 GB DDR5 laptop memory module in a single 262-pin SO-DIMM form factor. It operates at up to 5600 MT/s with CAS latency 46 and a 1.1 V supply, offering a direct upgrade path for notebooks that support DDR5 SO-DIMM. The module includes on-die error correction and an integrated Power Management IC to improve power delivery and stability while keeping the module compact and compatible with laptop installations.

Advantages

The module delivers higher operating frequencies compared with DDR4, enabling faster data throughput for multitasking and demanding applications. It uses lower voltage (1.1 V) and an integrated PMIC to reduce power consumption and stabilize power delivery. The DDR5 internal architecture allows greater effective capacity within the same module area, and on-die ECC improves data integrity and system reliability.

Suitable for

• Upgrading laptop memory for improved multitasking
• Content creation and media editing on supported notebooks
• System responsiveness and application loading speed improvements
• Enterprise-grade laptops that benefit from enhanced stability

Key specifications

• Capacity: 48 GB
• Memory type: DDR5
• Speed: 5600 MT/s (DDR5-5600)
• CAS latency: 46
• Form factor: 262-pin SO-DIMM (laptop module)
• Operating voltage: 1.1 V
• Integrated Power Management IC (PMIC)
• On-die Error Correcting Code (ECC)
• Module colour: Black

How to use

Power off the laptop and disconnect it from any power source. Open the laptop memory compartment according to the manufacturer’s service instructions, remove existing SO-DIMM modules if necessary, and install the ADATA 262-pin DDR5 module into an empty DDR5 SO-DIMM slot at the correct angle until the retaining clips engage. Reassemble the laptop and power it on; the system BIOS/UEFI should detect the new memory. Verify memory recognition and operating frequency in the BIOS/UEFI or the operating system.

Recommendations

Install this module only in laptops that explicitly support DDR5 SO-DIMM modules and DDR5-5600 speeds. For optimal results, pair with compatible memory configurations as specified by the laptop or motherboard vendor and ensure BIOS/UEFI is updated to the latest version.
