Motosierra Graphite 58G034

The GRAPHITE Chainsaw 58G034 is a battery-operated chainsaw powered by two 18 V rechargeable batteries and designed for cutting firewood and tree branches. The lightweight construction, 10" (250 mm) guide and 240 mm operating guide length provide a balance of maneuverability and cutting reach while the metal drive gear and automatic oil feeding system enhance durability and reduce wear. The saw includes a safety chain brake and an external hand guard to support safer operation during residential and light professional tasks.

Advantages

The saw offers a combination of portability and power thanks to dual 18 V battery operation and a no-load motor speed of 3300 min⁻¹. The automatic oil feeding system maintains proper lubrication of the chain to lower failure risk from incorrect maintenance. Tool-free chain tensioning and a comfortable handle simplify setup and handling. A safety brake and external hand guard add protection during cutting operations, while the metal drive gear increases resistance to mechanical wear.

Suitable for

• Cutting firewood and splitting branches
• Pruning and trimming medium-sized trees
• Home and garden maintenance tasks
• Light professional landscaping and arborist support work

Key specifications

• Power source: two 18 V rechargeable batteries (battery model not included)
• Motor speed (no load): 3300 min⁻¹
• Linear chain speed (no load): 6 m/s
• Guide type: 10" (250 mm)
• Operating guide length: 240 mm
• Chain pitch: 3/8" (9.525 mm)
• Chain thickness: 1.3 mm
• Chain oil tank capacity: 100 ml
• Safety features: safety chain brake, external hand guard
• Additional features: automatic oil feeding, tool-free chain tensioning, comfortable handle, metal drive gear
• Weight: 3.2 kg

How to use

Before use, install and fully charge the two 18 V batteries according to the battery manufacturer’s instructions. Fill the chain oil tank to the specified capacity and check that the automatic oil feeding system is functioning. Use the tool-free chain tensioning system to set chain tension correctly before each session. Hold the saw with both hands using the comfortable handle and keep the external hand guard between the operator and the bar tip. Engage the safety chain brake when starting maintenance or moving between cuts. Operate the saw with steady, controlled movements, allowing the chain to cut at its designed speed without forcing the tool.

Recommendations

For safe and reliable operation, use the chainsaw with compatible 18 V rechargeable batteries and regularly maintain the chain, guide bar and oil system. Wear appropriate personal protective equipment including eye protection, gloves and hearing protection. Avoid cutting above shoulder height, and follow local safety regulations and battery handling guidelines.
