NEO TOOLS Broca SDS Max para hormigón 24 x 600 mm S4 Quatro

Concrete drill bit with SDS Max shank, 24 mm diameter, and 600 mm total length, engineered for high-speed drilling in reinforced concrete. The quadruple flute design with four tungsten carbide cutters and a centering tip delivers rapid material removal and precise hole starts, while the reinforced core and heat-treated alloy steel body withstand heavy-duty rotary hammer use.

Advantages

Quadro tip geometry with four carbide cutters ensures fast, efficient drilling and long service life even in tough aggregate. Optimized flute shape promotes effective dust extraction, reducing clogging and heat buildup. Vibration-reducing design improves operator comfort during extended use. Complies with DIN ISO 5468 for consistent quality and performance.

Suitable for

• Concrete and reinforced concrete
• Masonry and brickwork
• Natural stone
• SDS Max rotary hammer drills

Key specifications

• Diameter: 24 mm
• Total length: 600 mm
• Working length: 540 mm
• Shank: SDS Max
• Number of cutters: 4 (Quatro)
• Cutter material: Tungsten carbide
• Body material: High-grade alloy steel
• Flute design: Quadruple
• Centering tip for accurate starts
• Heat-treated for durability
• Reinforced core
• Optimized dust removal
• Vibration reduction
• Colour: Silver/Grey
• Packaging: Single unit

Recommendations

For best results, use with an SDS Max rotary hammer drill in hammer mode. Apply steady pressure and periodically withdraw the bit to clear debris. Suitable for professional construction and renovation tasks requiring large-diameter holes in concrete.
