KUZ-VO KB caja de instalación eléctrica para aislamiento térmico, ajustable 30-250 mm, PP autoextinguible, naranja

Accommodating insulation thicknesses from 30 to 250 mm, the KUZ-VO KB adjustable installation box eliminates thermal bridging in external insulation systems. Its self-extinguishing, halogen-free polypropylene body ensures fire-safe electrical installations across a temperature range of -25 °C to +60 °C, while pre-marked cable knockouts streamline wiring.

Overview

The KUZ-VO KB from KOPOS is a single-gang installation box designed for flush mounting within ETICS. It provides a stable, fire-safe housing for switches, sockets, and other electrical devices, while its adjustable depth adapts to various insulation thicknesses. Pre-marked cable knockouts simplify wiring, and the halogen-free construction meets stringent safety standards.

What stands out

• Adjustable for insulation thicknesses from 30 to 250 mm, ensuring a perfect fit for diverse ETICS projects.
• Self-extinguishing polypropylene construction enhances fire safety and is halogen-free.
• Prevents thermal bridging, maintaining insulation effectiveness and reducing energy loss.
• Complies with EN 60670-1 and EN 60670-22 standards, guaranteeing quality and reliability.
• IP30 protection degree suitable for dry indoor and protected outdoor environments.

Technical details

• Product Type: Installation box for thermal insulation systems
• Application: External Thermal Insulation Composite Systems (ETICS)
• Insulation Thickness Compatibility: 30 - 250 mm (adjustable)
• Material: Self-extinguishing Polypropylene (PP)
• Color: Orange
• Base Box Dimensions (L x W x D): 120 x 120 x 100 mm
• Mounting Method: Flush-mounted in insulation
• Thermal Bridge Prevention: Yes
• Temperature Resistance: -25 °C to +60 °C
• Protection Degree (IP Rating): IP30
• Flammability Rating: Self-extinguishing
• Halogen-free: Yes
• Cable Entry Type: Pre-marked knockouts
• Device Compatibility: Standard switches, sockets, and other electrical devices
• Standard Compliance: EN 60670-1, EN 60670-22
• Number of Gangs/Modules: Single gang
• Installation Depth: Adjustable based on insulation thickness
• Usage Environment: Outdoor/Indoor (when installed in external insulation)

Our verdict

With its adjustable depth, fire-safe materials, and thermal bridge prevention, the KUZ-VO KB is a reliable choice for any ETICS installation requiring flexibility and compliance.
