Tubo de chimenea de diámetro 160 mm, 1 m, acero negro, una pared, alta temperatura

Proper flue gas exhaust is critical for the safe and efficient operation of solid fuel heating systems. This 160 mm diameter chimney liner pipe, 1 meter in length, provides a robust and reliable solution for constructing or extending chimney systems. Made from black steel with a high-temperature paint finish, it is engineered to handle the demands of wood, coal, and other solid fuel applications. Its modular spigot and socket connection ensures a secure fit and straightforward assembly, making it suitable for both new installations and repairs.

Who is it for

This liner pipe is ideal for homeowners, installers, and heating professionals who need a durable and certified component for solid fuel chimney systems. It is particularly suited for internal, dry operating conditions where a single-wall pipe is appropriate, such as connecting a stove to an existing masonry chimney or creating a complete flue run in a well-ventilated space.

Main features

• Nominal diameter of 160 mm for efficient flue gas flow.
• Length of 1000 mm (1 meter) for flexible system design.
• Constructed from black steel with a material thickness of 0.6 mm for strength and longevity.
• High-temperature black paint finish withstands up to 600°C.
• Spigot and socket connection for easy, secure assembly without special tools.
• CE certified and soot fire resistant for added safety.
• Compatible with solid fuels including wood and coal.

Specifications

• Product Type: Chimney Liner Pipe
• Material: Black Steel
• Nominal Diameter: 160 mm
• Length: 1000 mm (1 Meter)
• Wall Construction: Single Wall
• Material Thickness: 0.6 mm
• Connection Type: Spigot and Socket (Male/Female)
• Maximum Operating Temperature: 600°C
• Fuel Type Compatibility: Wood, Coal, Solid Fuels
• Application: Flue Gas Exhaust, Chimney Lining
• Finish: High-Temperature Black Paint
• Corrosion Resistance: Moderate (suitable for dry operating conditions)
• Pressure Class: N1 (Negative Pressure)
• Soot Fire Resistance: Yes
• Certification: CE Certified
• Installation: Internal, Dry Operation
• Shape: Round
• System Compatibility: Modular system for easy assembly
• Joint Sealing: Requires high-temperature sealant (not included)

Tips

For optimal performance, ensure the pipe is installed in a dry, well-ventilated area and use a high-temperature sealant on joints to prevent leaks. Regular inspection and cleaning are recommended to maintain safety and efficiency.
