OBO BETTERMANN 2031 M 15 FS Grip clip recogecables para 15x NYM-J 3x1,5 mm², gris claro

For secure bundling of up to 15 sheathed cables, the OBO BETTERMANN 2031 M 15 FS Grip cable collecting clip offers a robust, halogen-free solution in light grey (RAL 7035). Its polyamide construction with a single screw mounting point ensures fast, reliable installation on walls or panels, keeping cable runs neat and protected.

Advantages

The clip's open design allows cables to be inserted or removed without dismounting, simplifying maintenance. The high-quality polyamide material is silicone-free and halogen-free, making it suitable for environments with strict fire safety requirements. The integrated strain relief prevents cable movement and reduces stress on connections.

Suitable for

• Indoor cable management in residential and commercial buildings
• Bundling NYM-J 3x1.5 mm² installation cables
• Organizing cable runs along walls, ceilings, or inside distribution boards
• Applications requiring halogen-free and silicone-free components

Key specifications

• Type: Cable collecting clip
• Material: Polyamide (PA)
• Color: Light grey (RAL 7035)
• Mounting: Screw mounting with 6 mm fixing hole
• Number of cables: 15
• Compatible cable type: NYM-J 3x1.5 mm²
• Max cable outer diameter: approx. 9.5 mm
• Temperature resistance: -20 to +90 °C
• Glow-wire test: 850 °C
• Halogen-free: Yes
• Silicone-free: Yes
• RoHS compliant: Yes

Recommendations

For optimal performance, use with OBO BETTERMANN mounting screws and ensure the fixing surface is flat and stable. Space clips at regular intervals to prevent sagging and maintain a professional appearance.
