OBO PLM D 0404 RW canal de instalación metálico con tejido de protección contra incendios 40x40x2000 mm, blanco 7218002

In buildings where electrical and data cables must remain functional during a fire, standard cable routing fails. The OBO PLM D 0404 RW metal installation channel solves this by integrating a fire protection fabric that maintains circuit integrity under fire conditions. This 40x40 mm channel, 2000 mm long, is made of powder-coated steel in pure white (RAL 9010) and provides a single compartment with a snap-on cover. It mounts on walls and ceilings and is halogen-free, making it suitable for safety-relevant installations.

Who is it for

Electricians and facility planners installing cable routes in public buildings, tunnels, or industrial facilities where functional integrity during fire is required by building codes.

Main features

• Integrated fire protection fabric for functional integrity
• Robust steel construction with white powder coating
• Dimensions: 40 mm width, 40 mm height, 2000 mm length
• Snap-on cover for easy access
• Halogen-free material
• Wall and ceiling mounting

Specifications

• Product type: Metal installation channel
• Material: Steel
• Colour: White (RAL 9010)
• Surface finish: Powder-coated
• Number of compartments: 1
• Cover type: Snap-on
• Mounting type: Wall and ceiling
• Halogen-free: Yes
• Series: PLM-D

Tips

Combine with matching OBO PLM-D accessories for corners, bends, and end pieces to complete your installation. Ensure proper fastening intervals according to local regulations for fire-rated cable support systems.
