Patchsee ThePATCHCORD Cable de red RJ45 Cat. 6A, U/UTP, extrafino, naranja, 1,5 m (TPC-SO-U/5)

Tracking down a specific network cable in a crowded rack is a common headache. The Patchsee ThePATCHCORD solves this with a visual identification system that lets you trace a port by injecting light into the cable, making it glow at the far end. This 1.5 m orange Cat. 6A U/UTP patch cable is extra thin, ideal for high-density patching where space is tight.

Who is it for

Network administrators, data center technicians, and office IT staff who need reliable 10 Gigabit Ethernet connectivity and quick cable identification without tracing bundles by hand.

Main features

• Cat. 6A performance with up to 500 MHz bandwidth and 10 Gbps data transfer rate
• Unshielded U/UTP construction with 28 AWG stranded copper conductors for flexibility
• Extra thin outer diameter of approximately 3.8 mm, saving space in high-density installations
• RJ45 male to RJ45 male connectors, wired to TIA/EIA-568B standard
• PVC jacket in orange for high visibility
• Visual identification system (light injection) for easy port tracing

Specifications

• Cable length: 1.5 m
• Colour: Orange
• Category: Cat. 6A
• Shielding: U/UTP
• Connector type: RJ45 male to RJ45 male
• Data transfer rate: 10 Gbps
• Bandwidth: 500 MHz
• Conductor gauge: AWG 28
• Conductor material: Copper
• Jacket material: PVC
• Outer diameter: 3.8 mm
• Wiring standard: TIA/EIA-568B
• Impedance: 100 Ohm
• Operating temperature: -20°C to +60°C

Tips

Pair this cable with a Patchsee light source to use the visual identification feature. The slim profile is perfect for dense patch panels and cable managers, but avoid sharp bends to protect the stranded conductors.
