Phoenix Contact 1404199 Cable de sensor/actuador, conector macho M12 a extremo abierto, 4 polos, codificación A, apantallado, PUR, 1,5 m

Industrial environments demand reliable signal transmission despite constant motion, vibration, and exposure to oils and chemicals. This Phoenix Contact sensor/actuator cable solves that challenge by providing a robust, shielded connection between M12-equipped sensors or actuators and control systems. With a 4-pin A-coded M12 plug on one end and a free cable end on the other, it offers flexible installation while maintaining a secure, IP67-rated link when mated. The 1.5-meter length is ideal for connecting devices in tight spaces or for short runs within machinery.

Who is it for

Automation engineers, panel builders, and maintenance technicians who need dependable connectivity for sensors, actuators, and field devices in factory automation, robotics, and process control. It is especially suited for applications where cables are subject to frequent flexing, exposure to cutting fluids, or electromagnetic interference.

Main features

• Shielded 4-position M12 plug with A-coding for sensor/actuator signals
• Free cable end for custom termination or direct wiring to terminal blocks
• PUR (polyurethane) jacket that is halogen-free, oil-resistant, and flame-retardant
• High ingress protection: IP65, IP67, and IP68 when properly connected
• Wide operating temperature range from -25 °C to 90 °C
• Rated for 250 V AC/DC and 4 A, suitable for many industrial sensors

Specifications

• Brand: Phoenix Contact
• Model: 1404199
• MPN: 1404199
• EAN: 4046356681193
• Cable length: 1.5 m
• Connector 1: M12 plug, straight, male
• Connector 2: free cable end
• Number of positions: 4
• Coding: A-coded
• Shielding: yes
• Cable material: PUR (polyurethane), halogen-free
• Cable colour: black-grey
• Rated voltage: 250 V AC/DC
• Rated current: 4 A
• Conductor cross-section: 0.34 mm² (AWG 22)
• Degree of protection: IP65, IP67, IP68 (when connected)
• Operating temperature: -25 °C to 90 °C
• Outer cable diameter: 5.9 mm
• Contact material: CuSn
• Contact surface: Ni/Au
• Housing material: TPU
• Sealing material: NBR
• Pollution degree: 3
• Halogen-free: yes

Tips

For best results, ensure the M12 connector is fully tightened to achieve the specified IP rating. When routing the cable, avoid sharp bends below the minimum bend radius to prolong service life. The free end can be terminated with Phoenix Contact terminal blocks or other compatible connectors for custom installations.
