Phoenix Contact CLIPFIX 5022627 Adaptador universal de montaje en carril DIN, poliamida transparente, 42 x 9,5 x 22 mm

For mounting components on standard DIN rails without tools, the Phoenix Contact CLIPFIX 5022627 offers a transparent clip-on adapter that snaps securely onto NS 35 and NS 32 profiles. Its compact 42 mm length and halogen-free polyamide body make it a practical alternative to metal brackets in space-constrained control cabinets.

Highlights

• Tool-free clip-on mounting for fast assembly
• Compatible with NS 35 (EN 60715) and NS 32 DIN rails
• Transparent polyamide housing for visual inspection of rail engagement
• Wide operating temperature range from -60 °C to 105 °C
• UL 94 V2 flammability rating for enhanced safety

In daily use

The CLIPFIX adapter grips the rail firmly yet releases easily when needed, reducing installation time during panel building. Its small footprint leaves adjacent rail space free for terminals and other devices, while the halogen-free material supports compliance with environmental requirements in sensitive applications.

Full specifications

• Product type: Universal mounting adapter
• Mounting method: Clip-on
• Compatible DIN rails: NS 35 (EN 60715), NS 32
• Material: Polyamide (PA)
• Colour: Transparent
• Operating temperature: -60 °C to 105 °C
• Flammability rating: UL 94 V2
• RoHS compliant
• REACH compliant
• Halogen-free
• Product family: CLIPFIX
• Dimensions (L x W x H): 42 x 9.5 x 22 mm
• Weight per piece: 2.5 g
• Standards: EN 60715

Final note

This adapter is a genuine Phoenix Contact accessory, identified by MPN 5022627 and EAN 4017918095222, ensuring reliable performance in industrial environments.
