PULS MiniLine ML30.101 fuente de alimentación para carril DIN 5V DC 5A 25W

In industrial control cabinets and building automation panels, the PULS MiniLine ML30.101 provides a regulated 5 V DC output for powering sensitive electronics, sensors, and controllers. Its compact DIN rail housing and convection cooling make it suitable for tight spaces where reliable low-voltage power is essential.

Key specifications

• Output voltage: 5 V DC
• Output current: 5 A
• Output power: 25 W
• Input voltage: 85–264 V AC or 90–300 V DC
• Efficiency: 87.0%
• Mounting: DIN rail TS35/7.5 or TS35/15
• Operating temperature: -10 °C to +70 °C
• Protection: overload, short-circuit, over-temperature, over-voltage
• Connection: screw terminals
• Ripple and noise: <50 mVpp
• Hold-up time: >20 ms at 230 V AC
• MTBF: >1,000,000 hours per IEC 61709
• Degree of protection: IP20
• Housing material: plastic (polycarbonate)
• Cooling: convection

Why choose it

The ML30.101 combines high efficiency with a wide input voltage range, allowing operation from unstable mains or DC sources. Its robust design and comprehensive protection features ensure long-term reliability in industrial environments.

Ideal use cases

• Powering 5 V logic circuits and microcontrollers
• Supplying sensors and actuators in automation systems
• Building automation and HVAC control panels
• Test and measurement equipment

Good to know

The unit is convection cooled, eliminating fan noise and maintenance. Screw terminals provide secure wiring, and the plastic housing offers electrical isolation.
