PULSAR AWZ575 Módulo de fusibles 8 canales 1A fusible de vidrio 10-30V DC

The PULSAR AWZ575 is a professional 8-channel fuse module designed for reliable overcurrent protection in CCTV, access control, and alarm systems. It accepts an unregulated DC input from 10V to 30V and distributes it to eight individually fused outputs, each protected by a standard 5x20mm glass fuse rated at 1A. The module features LED indicators for each channel to quickly identify a blown fuse, simplifying maintenance. Housed in a compact ABS plastic enclosure, it can be surface-mounted on a wall and connected via screw terminals. With CE certification and an IP20 rating, the AWZ575 is a robust solution for distributing power in security and low-voltage installations.

Advantages

• Individual channel fusing with visual LED status for easy troubleshooting
• Wide input voltage range (10-30V DC) compatible with many power supplies
• Compact design saves space in enclosures and cabinets
• Screw terminals ensure secure and reliable connections

Suitable for

• CCTV systems requiring multiple camera power feeds
• Access control systems with multiple locks or readers
• Alarm panels and security system power distribution
• Any low-voltage DC installation needing organized fused outputs

Key specifications

• Number of Outputs: 8 channels
• Output Fuse Type: Glass fuse (5x20mm)
• Standard Fuse Rating per Channel: 1A
• Total Output Current (Max): 8A
• Input Voltage Range: 10V - 30V DC
• Output Voltage: Unregulated (equal to input voltage)
• Protection Features: Overload, Short-circuit (via fuses)
• Fuse Status Indication: 8x LED (one per channel)
• Mounting Type: Surface mount (wall-mounted)
• Connection Type: Screw terminals
• Operating Temperature: -10°C to +40°C
• Housing Material: Plastic (ABS)
• Dimensions (W x H x D): 120 x 93 x 35 mm
• Weight: 0.1 kg
• Protection Class: IP20
• Certifications: CE

Recommendations

For optimal performance, use with a regulated DC power supply rated at least 8A. Ensure the total current draw of all connected devices does not exceed 8A. Replace blown fuses only with the same type and rating (1A, 5x20mm glass).
