Reely RE-6605868 Motor brushless 3600KV sensorless inrunner 28x38mm eje 3,175mm 2-3S LiPo

This Reely brushless motor stands out with its 3600 KV rating and sensorless inrunner design, delivering high RPM per volt for 1:16 and 1:18 scale RC cars, buggies, and trucks. It offers a compact 28 mm diameter and 38 mm body length, making it a direct performance upgrade or replacement for stock motors.

Highlights

• 3600 KV sensorless inrunner for high-speed applications
• Aluminum alloy housing with 3.175 mm shaft
• Supports 2-3S LiPo batteries (7.4V - 11.1V)
• Max continuous current 40 A, power output 500 W
• 3.5 mm gold bullet connectors for reliable power transfer

In daily use

The motor's 4-pole design and M3 mounting holes ensure stable installation and smooth operation. With a maximum voltage of 11.1V, it delivers consistent power for demanding RC driving. The inrunner configuration provides efficient cooling and high torque density.

Full specifications

• Motor type: Brushless, sensorless inrunner
• KV rating: 3600 RPM/V
• Diameter: 28 mm
• Body length: 38 mm
• Shaft diameter: 3.175 mm
• Shaft length: 15 mm
• Max voltage: 11.1V (3S LiPo)
• Max continuous current: 40 A
• Max power output: 500 W
• Number of poles: 4
• Connector type: 3.5 mm gold bullet plugs
• Housing material: Aluminum alloy
• Mounting hole size: M3

Final note

Ideal for hobbyists seeking a reliable, high-performance brushless motor for smaller-scale RC vehicles.
