Regulador de presión EINHELL 2332399, regulador de presión interior 50 mbar para calefactores de gas interiores

Einhell 2332399 pressure regulator is a single-piece silver regulator designed to control gas flow and pressure for compatible grills, heaters and gas systems. It is intended for installations where the inlet pressure does not exceed 0.3 bar and the outlet pressure is regulated up to 16 bar, and is supplied as one unit for connection to suitable gas cylinders and appliances. The regulator includes safety and monitoring features appropriate for indoor household and certain commercial applications where specified standards apply.

Advantages

The regulator provides stable pressure control for gas appliances and incorporates an integrated inspection pressure gauge to allow gas-tightness checks. A thermal shut-off device interrupts gas supply if temperatures rise above 100 °C, and an overpressure safety device ensures that if one stage fails the remaining stage limits pressure to a safe maximum. The compact single-piece construction and silver finish make it easy to install and visually unobtrusive.

Suitable for

• Connecting compatible grills and outdoor cooking equipment where specified pressure limits match
• Domestic gas heaters and cookers that require a regulated outlet pressure within the stated range
• Gas systems using 5 kg or 11 kg gas cylinders where certified regulator use is required

Key specifications

• Product colour: Silver
• Maximum inlet pressure: 0.3 bar
• Maximum outlet pressure: 16 bar
• Integrated inspection pressure gauge for leak testing
• Thermal shut-off device activates above 100 °C
• Overpressure safety device with dual-stage protection limiting to 100 mbar if one stage fails
• Suitable for 5 kg and 11 kg gas cylinders
• Inlet connection: left-handed thread (KLF W21.8 x 1/14")
• Outlet connection: G1/4 LH-KN thread
• Compliance: EN 12864 and DIN 4815 F1-t (certified for specified indoor and commercial uses)

How to use

Install the pressure regulator on the compatible gas cylinder and connect the outlet to the appliance using the matching G1/4 LH-KN thread. Before first use and after any reconnection, check the system for gas-tightness using the integrated inspection pressure gauge. Ensure the regulator is used with appliances and hose lengths that meet the applicable installation regulations and do not exceed the stated pressure limits. Follow appliance manufacturer instructions and local regulations for gas installations.

Recommendations

Use the regulator only with compatible appliances and approved hose assemblies. Verify certification and suitability for indoor or commercial use according to local rules. Do not expose the regulator to temperatures that could trigger the thermal shut-off except as designed; if the thermal shut-off or overpressure protection engages, stop use and inspect the installation before reconnecting.
