Renkforce RF-4707810 pulsador de timbre de acero inoxidable 1 vía 24 V/1 A

Upgrade your entryway with the Renkforce RF-4707810 doorbell button, a robust and elegant solution for residential and commercial buildings. Crafted from high-quality stainless steel, this single-gang bell push combines durability with a modern aesthetic, making it ideal for front doors, gates, and access control systems. The integrated blue ring illumination ensures the button is easily visible even in low-light conditions, while the IP65 protection rating guarantees reliable operation in outdoor environments exposed to dust and rain.

Key specifications

• Product type: Doorbell button / bell push
• Number of gangs: 1 (single)
• Material: Stainless steel
• Switching voltage: 24 V AC / 24 V DC
• Max. switching current: 1 A
• Contact type: 1 NO (normally open)
• Mounting type: Flush mount
• Installation diameter: 19 mm
• Installation depth: 15 mm
• Panel thickness range: 1 - 10 mm
• Connection type: Solder connection
• Protection class: IP65
• Illumination: Ring illumination, blue
• Illumination voltage: 12 V DC, 24 V DC
• Illumination current: 20 mA
• Operating temperature: -20 to +55 °C
• Electrical life: 200,000 cycles
• Mechanical life: 1,000,000 cycles

Why choose it

The RF-4707810 stands out for its premium stainless steel construction, which resists corrosion and wear, ensuring a long service life even in harsh weather. The blue illuminated ring not only adds a touch of sophistication but also helps visitors locate the button quickly. With a wide operating temperature range and high mechanical endurance, this button is built to perform reliably for years. Its flush mount design allows for a clean, integrated look on any surface.

Ideal use cases

• Residential front doors and apartment intercoms
• Commercial building entrances and office access systems
• Gates, fences, and outdoor access points
• Industrial facilities requiring durable control buttons
• Public buildings with high traffic and vandalism concerns

Good to know

Installation is straightforward thanks to the standard 19 mm mounting hole and solder terminals for secure wiring. The button is compatible with most low-voltage doorbell systems operating at 24 V AC or DC. Please note that a suitable power supply and chime are not included. For outdoor use, ensure proper sealing around the mounting hole to maintain the IP65 rating.
