Rittal AX Junta modular, cerrada, 20 x 20 mm, pack de 10 2580000

In control cabinet builds, unused openings in modular gland plates can compromise ingress protection and cable management. The Rittal AX modular sealing insert closes these 20 x 20 mm openings quickly and securely, maintaining a clean, protected enclosure interior.

Key specifications

• Product type: Sealing insert
• Series compatibility: Rittal AX
• Design: Modular, closed
• Opening dimension: 20 x 20 mm
• Material: Plastic
• Colour: Jet black (RAL 9005)
• Mounting method: Snap-in
• Pack quantity: 10 pieces

Why choose it

This sealing insert is designed for use with Rittal AX modular gland plates. It snaps into place without tools, allowing fast installation and removal when cable configurations change. The closed design blanks off unused openings, helping to maintain the enclosure's ingress protection rating when used with a compatible gland plate.

Ideal use cases

• Sealing unused cable entry openings in Rittal AX enclosures
• Maintaining IP protection in industrial control panels
• Modifying cable routing without replacing the gland plate
• Organising spare openings for future expansion

Good to know

The insert is made of plastic and supplied in a pack of 10. It is a system component for Rittal AX modular gland plates and is suitable for operating temperatures from -40 °C to +80 °C.
