Router inalámbrico Cudy AX3000 (Wi‑Fi 6 dual band 2,4/5 GHz, Gigabit Ethernet, 4x LAN, 2402+574 Mbit/s)

The router delivers super-fast Wi-Fi using Wi‑Fi 6 with up to 160 MHz channel bandwidth and 1024‑QAM, enabling wireless speeds up to 3 Gbps. With five spatial streams (three on 5 GHz and two on 2.4 GHz), high‑gain antennas and Beamforming, it extends coverage across the home and improves signal stability through obstacles. The device supports connection of many clients and includes features for privacy, remote access and parental control.

Advantages

This Wi‑Fi 6 router offers higher throughput than previous AC 2x2 models, broader coverage through five streams and beamforming, and the ability to maintain lower latency with multiple simultaneous connections. It is designed to handle up to 200 active devices and a maximum of 512 devices overall. Additional functions include VPN server/client support, DNS over TLS encryption, Cudy Mesh compatibility, IPTV port configuration and mobile management via the Cudy App.

Key specifications

• Wi‑Fi standard: Wi‑Fi 6 (802.11ax)
• Maximum wireless speed: up to 3 Gbps (combined)
• Channel bandwidth: up to 160 MHz
• Modulation: 1024‑QAM
• Spatial streams: 5 (3× on 5 GHz, 2× on 2.4 GHz)
• Supported client capacity: designed for 200 active devices, max 512 devices
• Antennas: high‑gain external antennas with Beamforming
• VPN: server and client support (requires firmware newer than 1.16.1)
• DNS encryption: DNS over TLS (Cloudflare, Google, Quad9)
• Mesh: Cudy Mesh compatible
• IPTV: dedicated LAN port configuration for IPTV
• Management: Cudy App with local and cloud remote control

How to use

Connect the router to your modem and power it on, then use the Cudy App or the web interface to run the initial setup wizard: set an administrator password, configure SSID and Wi‑Fi passwords for 2.4 GHz and 5 GHz bands, and select channel bandwidth settings. Enable VPN server or client if remote secure access is required (ensure firmware is updated beyond version 1.16.1). For IPTV, assign the specific LAN port to the IPTV service in the interface. To expand coverage, add compatible Cudy Mesh nodes and enable mesh mode for seamless roaming.

Recommendations

Place the router in a central, elevated location away from large metal objects and microwave ovens to improve coverage. Update firmware before enabling advanced features like VPN. Use the Cudy App for easier device management and parental control scheduling.
