RUKO FRS-DIN8033-HM-TiAlN-Ø10,0mm fresa de mango VHM, 4 filos, recubierta de TiAlN, DIN 8033, diámetro de corte 10 mm, longitud 72 mm

Precision milling in tough materials demands a tool that resists wear and maintains sharpness under high temperatures. The RUKO FRS-DIN8033-HM-TiAlN-Ø10,0mm solid carbide end mill addresses this challenge with a TiAlN coating and a 45° helix angle, enabling efficient chip evacuation and extended tool life in steel, stainless steel, cast iron, titanium alloys, and high-temperature alloys.

Who is it for

CNC machinists, toolmakers, and manufacturing professionals who need a reliable end mill for general-purpose milling, slotting, and profiling operations. It suits both wet and dry machining environments.

Main features

• Solid carbide (HM) construction for high rigidity and wear resistance.
• TiAlN (Titanium Aluminum Nitride) coating for thermal stability and reduced friction.
• DIN 8033 standard geometry with 4 flutes and 45° helix angle.
• Square end (flat end) cutting edge for sharp 90° corners.
• Cylindrical shank with h6 tolerance for precise tool holding.

Specifications

• Cutting diameter (d1): 10.0 mm
• Shank diameter (d2): 10.0 mm
• Cutting length (L2): 22 mm
• Overall length (L1): 72 mm
• Number of flutes: 4
• Helix angle: 45°
• Coating: TiAlN
• Material: Solid carbide
• Shank type: Cylindrical
• Cutting edge type: Square end
• Standard: DIN 8033
• Machining suitability: Steel, stainless steel, cast iron, titanium alloys, high-temperature alloys
• Coolant application: Wet or dry

Tips

For optimal results, use a rigid setup and appropriate cutting parameters for the workpiece material. TiAlN coating performs best at high cutting temperatures, so dry machining or minimal coolant is often recommended.
