SATEL ANT-LTE-I Antena LTE con base magnética, cable de 3m, conector macho SMA

The SATEL ANT-LTE-I is a high-performance omnidirectional antenna designed for SATEL communication modules. It supports 2G, 3G, and 4G LTE networks, ensuring reliable connectivity for various applications. With a magnetic base and 3-meter cable, installation is quick and flexible.

Advantages

This antenna offers wide frequency coverage (698-960 MHz / 1710-2690 MHz) and a gain of 2 dBi, providing stable signal reception. The SMA male connector ensures compatibility with most SATEL modules. Its compact design and magnetic mount make it ideal for indoor use.

Suitable for

• SATEL communication modules
• 2G/3G/4G LTE networks
• Indoor applications requiring reliable cellular signal

Key specifications

• Frequency Range: 698-960 MHz / 1710-2690 MHz
• Antenna Gain: 2 dBi
• Connector Type: SMA Male
• Cable Length: 3 meters
• Mounting Type: Magnetic Base
• Impedance: 50 Ohm
• Polarization: Vertical
• VSWR: < 2.0
• Supported Networks: 2G (GSM), 3G (UMTS), 4G (LTE)
• Directionality: Omnidirectional
• Operating Temperature: -20°C to +55°C
• Color: Black
• Base Diameter: 30 mm
• Total Height: 300 mm

Recommendations

For optimal performance, place the antenna in a location with minimal obstructions. Ensure the magnetic base is securely attached to a metal surface. Compatible with SATEL modules featuring SMA female connectors.
