SATEL XD-2 Sensor universal (PIR y microondas)

The SATEL XD-2 is a high-performance universal sensor designed for indoor security applications. Combining passive infrared (PIR) and microwave detection technologies, it provides reliable intrusion detection with reduced false alarms. The sensor features a detection range of 15 m x 24 m with a 90° angle, making it suitable for medium to large rooms. It operates on 12 V DC power and includes a tamper-protected NC relay output. The XD-2 is EN 50131 Grade 2 compliant, ensuring professional-grade security.

Advantages

Dual technology (PIR + microwave) minimizes false alarms. Adjustable PIR and microwave sensitivity allows fine-tuning for specific environments. Digital signal processing (DSP) enhances detection accuracy. Anti-creep function prevents crawling intruders from bypassing detection. Compact white ABS housing blends with interior decor.

Suitable for

• Indoor security systems in residential and commercial buildings
• Areas requiring high detection reliability with low false alarm rates
• Integration with SATEL alarm control panels and other compatible systems

Key specifications

• Detection technology: Dual (PIR + Microwave)
• Detection range: 15 m x 24 m, 90°
• Power supply: 12 V DC (±15%)
• Current consumption: 15 mA (standby), 20 mA (max)
• Alarm output: NC relay
• Tamper protection: Yes (cover tamper)
• Operating temperature: -10°C to +55°C
• Recommended mounting height: 2.4 m
• Compliance: EN 50131 Grade 2
• Microwave frequency: 24.125 GHz
• Housing material: ABS plastic
• Color: White

Recommendations

Mount at the recommended height of 2.4 m for optimal coverage. Avoid placing near heat sources, air vents, or direct sunlight to prevent false alarms. Use with SATEL control panels for best compatibility. The sensor supports selectable EOL resistors for integration with various alarm systems.
