Scharnberger 58491 transformador electrónico 12V AC 0-60W para halógeno o LED, 71,5x35x23,5mm

The Scharnberger 58491 is a high-quality electronic transformer designed for low-voltage lighting applications. It converts 230V AC input to 12V AC output, supporting both halogen and LED lamps with a power range from 0 to 60W. Its compact dimensions (71.5x35x23.5mm) make it ideal for built-in installations where space is limited.

Advantages

This transformer offers reliable performance with built-in protection against overload, short circuit, and overheating. It is dimmable when used with a suitable dimmer, providing flexibility in lighting control. The instant start-up ensures immediate illumination without delay.

Suitable for

• Low-voltage halogen and LED lighting systems
• Built-in installations in furniture, ceilings, or walls
• Residential and commercial lighting projects requiring a compact transformer

Key specifications

• Input voltage: 230V AC, 50/60 Hz
• Output voltage: 12V AC
• Maximum output power: 60W
• Minimum output power: 0W
• Maximum output current: 5A
• Housing material: Plastic
• Safety certification: CE
• Dimensions: 71.5 x 35 x 23.5 mm

Recommendations

For optimal performance, use with compatible dimmers designed for electronic transformers. Ensure proper ventilation during installation to maintain thermal protection.
