Schneider Electric ZENL1111 Harmony XALD/XALK carcasa vacía para aparatos de mando, 1 hueco, policarbonato, gris claro/amarillo, IP66/IP67/IP69/IP69K

The Schneider Electric ZENL1111 is a high-quality empty control station enclosure from the Harmony XALD/XALK series, designed for flush mounting in demanding industrial environments. This robust enclosure features a single cut-out and is constructed from durable polycarbonate, offering excellent resistance to impact, chemicals, and extreme temperatures. With its light grey base (RAL 7035) and yellow cover (RAL 1004), it provides high visibility and safety in the workplace.

Advantages

This enclosure offers superior protection with IP66, IP67, IP69, and IP69K ratings, making it suitable for harsh conditions including high-pressure washdowns. The IK07 impact rating ensures resistance against mechanical shocks. Its compact design with two knock-outs for cable glands (14 mm clamping capacity) simplifies installation. The Class II electrical shock protection and compliance with international standards guarantee safe operation.

Suitable for

• Industrial control stations
• Automation and process control
• Harsh environments requiring high ingress protection
• Applications needing flush mounting

Key specifications

• Product Range: Harmony XALD/XALK
• Product Type: Empty Control Station Enclosure
• Device Short Name: ZENL
• Number of Cut-outs: 1
• Enclosure Material: Polycarbonate
• Base Colour: Light Grey (RAL 7035)
• Cover Colour: Yellow (RAL 1004)
• Cable Entry: 2 knock-outs for cable gland, 14 mm clamping capacity
• Mounting Type: Flush mounting
• IP Protection Rating: IP66, IP67, IP69, IP69K (IEC 60529)
• IK Protection Rating: IK07 (EN 50102)
• Operating Temperature: -40 to 70 °C
• Storage Temperature: -40 to 70 °C
• Standards: EN/IEC 60947-5-1, UL 508, CSA C22.2 No 14
• Certifications: CSA, UL, CCC, EAC, BV, DNV, GL, LROS, RINA
• Electrical Shock Protection: Class II (IEC 60536)
• Vibration Resistance: 10 gn (f=10…500 Hz) conforming to IEC 60068-2-6
• Shock Resistance: 50 gn for 11 ms conforming to IEC 60068-2-27
• Protective Treatment: TH

Recommendations

For a complete control station, pair this enclosure with compatible Harmony XALD/XALK push buttons, selector switches, and pilot lights. Ensure proper cable glands are used to maintain the IP rating.
