Siemens 3NC2263 Fusible cilíndrico 6A 500V AC 250V DC gG 10x38mm

Protect your cables and lines from overcurrent with the Siemens 3NC2263 cylindrical fuse link. This 6 A gG fuse is built for general industrial applications, offering reliable breaking capacity up to 100 kA. Its 10 x 38 mm size fits standard fuse holders, making it a direct replacement for maintenance and new installations.

Who is it for

Electricians and maintenance technicians who need a dependable fuse for industrial control panels, power distribution, and machine protection.

Main features

• Rated current: 6 A
• Rated voltage: 500 V AC / 250 V DC
• Operating class: gG (general purpose)
• Breaking capacity: 100 kA
• Dimensions: 10 x 38 mm
• Ceramic body with silver-plated copper contacts
• VDE approved

Specifications

• Fuse type: Cylindrical fuse link
• Standard: IEC 60269-2
• Power dissipation at rated current: 0.8 W
• Mounting type: For fuse holders (e.g., Siemens 3NC1 series)
• Operating temperature range: -20 to +50 °C
• Storage temperature range: -40 to +80 °C
• Blown fuse indicator: No
• Number of poles: 1

Tips

Always replace fuses with the same type and rating to maintain protection. Check the fuse holder compatibility before installation.
