Siemens SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D/T 6ES7193-6LF30-0AW0

Engineered for SIMATIC ET 200SP, this BaseUnit provides a robust foundation with push-in terminals and a single potential group (P16) plus two internally bridged terminals, enabling fast, tool-free wiring and reliable power distribution.

Overview

The Siemens 6ES7193-6LF30-0AW0 is a BaseUnit type BU15-P16+A0+2D/T designed for the SIMATIC ET 200SP distributed I/O system. It accommodates Type A0 modules and features a light gray housing for DIN rail mounting. With push-in terminals, installation is quick and secure, reducing wiring time and errors.

What stands out

• Push-in terminals for tool-free, vibration-resistant connections
• One potential group (P16) with two internally bridged terminals for efficient power distribution
• Wide operating temperature range: -30 to +60 °C (horizontal mounting)
• Compact design for space-saving DIN rail installation

Technical details

• Product type: BaseUnit
• System compatibility: SIMATIC ET 200SP
• BaseUnit type: BU15-P16+A0+2D/T
• Module type compatibility: Type A0
• Terminal type: Push-in terminals
• Number of potential groups: 1 (P16)
• Number of jumper contacts: 2
• Color code: Light gray
• Mounting type: DIN rail
• Operating temperature (horizontal): -30 to +60 °C
• Operating temperature (vertical): -30 to +50 °C
• Storage temperature: -40 to +70 °C
• Protection class: IP20

Our verdict

A reliable and efficient BaseUnit for ET 200SP installations, offering push-in convenience and robust temperature tolerance for industrial environments.
