Sonoff THR320D TH Elite interruptor inteligente WiFi de control de temperatura y humedad

The Sonoff THR320D TH Elite is a smart WiFi temperature and humidity monitoring switch designed for precise environmental control. With a 20A relay and support for multiple sensors, it is ideal for applications such as indoor swimming pools, wineries, terrariums, home heating, irrigation systems, and greenhouses. The device features an LCD screen for real-time monitoring and integrates seamlessly with the eWeLink app for remote control and automation.

Advantages

Remote control via eWeLink app from anywhere; real-time temperature and humidity monitoring; supports multiple sensor types including DS18B20, SI7021, and MS01; compatible with Amazon Alexa and Google Assistant; LAN support for offline operation; 8 programmable schedules and timers; historical data storage up to 6 months in the cloud; DIN rail mounting for easy installation.

Suitable for

• Indoor swimming pools and wineries
• Terrariums and greenhouses
• Home heating and underfloor heating
• Irrigation systems
• Any environment requiring precise temperature and humidity control

Key specifications

• Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4GHz
• Input Voltage: 100-240V AC 50/60Hz
• Output Voltage: 100-240V AC 50/60Hz
• Max Load Current: 20A
• Max Load Power: 4400W
• Number of Channels: 1
• Sensor Interface: RJ9 (4P4C)
• Compatible Sensors: Sonoff THS01 (Temp & Hum), DS18B20 (Waterproof Temp), MS01 (Soil Moisture)
• Display: LCD Screen
• Control App: eWeLink
• Voice Assistant: Amazon Alexa, Google Assistant
• Mounting: DIN Rail
• Enclosure Material: PC V0 (Fire-retardant)
• Operating Temperature: -10°C to 40°C
• Operating Humidity: 5%-95%RH, Non-condensing
• Historical Data Storage: 6 months (eWeLink Cloud)
• Automation: Smart Scenes, Timers, Threshold Triggers
• Security: WPA/WPA2
• Microcontroller: ESP32

Recommendations

For optimal performance, use only compatible Sonoff sensors. Ensure the device is installed in a dry location within the specified temperature and humidity range. The THR320D is not suitable for outdoor use without additional protection.
