Soporte de monitor Ergotron LX Series 45-491-216

The Ergotron LX Series 45-491-216 Two-Monitor Mount is a dual side-by-side arm designed to support two monitors up to 27" (68.6 cm) each, with a maximum weight capacity of 18.1 kg. The white mount supports VESA sizes from 75 x 75 mm to 100 x 100 mm and provides height adjustment and a wide tilt range for flexible positioning and improved ergonomics.

Advantages

This dual monitor mount saves desk space by lifting screens off the surface and allows users to find the best view with smooth height adjustment and a tilt range of -75° to 75°. Its side-by-side arm design is suitable for low-angle or collaborative setups and the white finish integrates cleanly into most workspaces. Folding arms let you push screens aside to reclaim desk area when displays are not needed.

Suitable for

• Office workstations requiring two side-by-side monitors
• Home offices and remote work setups
• Trading desks, design studios, and collaborative workspaces
• Users who need adjustable height and tilt for ergonomic viewing

Key specifications

• Model: Ergotron LX Series 45-491-216
• Number of displays supported: 2
• Maximum screen size: 27" (68.6 cm) per display
• Maximum weight capacity: 18.1 kg
• VESA compatibility: 75 x 75 mm to 100 x 100 mm
• Tilt range: -75° to 75°
• Colour: White
• Product weight: 5.3 kg

How to use

Attach each monitor to the VESA plate (75 x 75 mm or 100 x 100 mm) and secure according to the monitor manufacturer’s instructions. Use the mount’s height adjustment to position screens at eye level and adjust tilt to reduce glare and obtain comfortable viewing angles. The side-by-side arms can be folded inward or pushed aside to free desk space when displays are not in use. Ensure total monitor weight does not exceed the specified capacity.

Recommendations

For safe and reliable operation, verify VESA compatibility and monitor weight before installation. Tighten mounting hardware securely and periodically check fasteners. Position monitors so the top of the screen is at or slightly below eye level to help maintain an ergonomic posture.
