Supermicro AOC-AG-i4M adaptador de red - módulo de E/S avanzado (AIOM) - 4 x Gigabit Ethernet

The Supermicro AOC-AG-i4M is a high-performance network adapter designed as an Advanced I/O Module (AIOM) for Supermicro servers and motherboards. It provides four Gigabit Ethernet ports powered by the Intel I350-AM4 controller, delivering reliable and efficient wired connectivity for enterprise data centers and cloud environments.

Advantages

This adapter offers exceptional value with its quad-port design, enabling high-density network connections in a compact AIOM form factor. It supports advanced features such as VLAN tagging, link aggregation, jumbo frames up to 9.5 KB, and iSCSI acceleration, enhancing network flexibility and performance. Energy Efficient Ethernet (EEE) reduces power consumption during low traffic, while Intel Virtualization Technology (VT-c) optimizes virtualized environments.

Suitable for

• Supermicro servers with AIOM slots
• Enterprise data centers requiring high port density
• Virtualized environments (VMware, Hyper-V, KVM)
• Network-attached storage (NAS) and storage area networks (SAN)
• Cloud computing and edge computing deployments

Key specifications

• Device Type: Network Adapter
• Form Factor: Advanced I/O Module (AIOM)
• Interface (Bus) Type: PCI Express 2.1 x4
• Ports: 4 x Gigabit Ethernet
• Data Link Protocol: Gigabit Ethernet, Fast Ethernet, Ethernet
• Data Transfer Rate: 1 Gbps per port
• Network Controller: Intel I350-AM4
• Cabling Type: Ethernet 1000Base-T, 100Base-TX, 10Base-T
• Jumbo Frame Support: Up to 9.5 KB
• VLAN Support: IEEE 802.1Q
• Teaming/Link Aggregation: IEEE 802.3ad
• iSCSI Support: Yes
• Energy Efficient Ethernet: IEEE 802.3az
• Intel VT-c: Yes
• Compliant Standards: IEEE 802.3, 802.3u, 802.3ab, 802.1Q, 802.1p, 802.3az, 802.3ad
• LED Indicators: Link/Activity/Speed per port

Recommendations

For optimal performance, pair this adapter with Supermicro motherboards that support AIOM. Ensure your system has an available PCI Express 2.1 x4 slot or compatible AIOM connector. This adapter is ideal for upgrading network connectivity in existing Supermicro servers without occupying a standard PCIe slot.
