Supermicro CBL-MCIO-1270OT4S2-85 Cable MCIO PCIe Gen5 x4, 85 cm, negro

The Supermicro CBL-MCIO-1270OT4S2-85 is a high-performance internal MCIO (Multi-Channel I/O) cable designed for PCIe Gen5 connectivity. It features an over-the-top (OT) routing design and is ideal for connecting NVMe SSDs or add-in cards to Supermicro motherboards with MCIO ports.

Advantages

This cable supports PCIe Gen5 data transfer rates of up to 32 GT/s per lane, ensuring maximum bandwidth for demanding applications. The 85 cm length provides flexibility in cable management within server or workstation chassis. Its shielded construction minimizes electromagnetic interference, guaranteeing reliable signal integrity.

Suitable for

• Supermicro servers and workstations with MCIO (SFF-TA-1016) connectors
• Connecting PCIe Gen5 NVMe SSDs or other high-speed devices
• Internal data center and enterprise storage systems

Key specifications

• Cable Type: MCIO (Multi-Channel I/O)
• Connector Type (Host): MCIO (SFF-TA-1016)
• Connector Type (Device): MCIO (SFF-TA-1016)
• PCIe Generation: Gen5
• Lane Configuration: x4
• Data Transfer Rate: 32 GT/s per lane
• Cable Length: 85 cm (33.5 inches)
• Routing Type: Over-The-Top (OT)
• Conductor Material: Copper
• Shielding: Yes
• Connector Orientation: Straight
• Colour: Black
• Operating Temperature: 0°C to 70°C

Recommendations

For optimal performance, ensure your motherboard supports PCIe Gen5 MCIO connections. This cable is a direct replacement for Supermicro OEM parts and is fully compatible with Supermicro systems featuring MCIO ports.
