SYNERGY21 LED-Controller EOS 05 Controlador de 4 canales con fuente de alimentación CV - 12V 100W

LED controller with integrated constant voltage power supply for 12V LED strips and modules. Delivers up to 100W across 4 output channels with PWM dimming from 0-100%.

Advantages

Combines controller and power supply in one unit, reducing wiring and space. Four channels allow independent control of RGB, RGBW or single-color LED groups. PWM dimming ensures smooth, flicker-free brightness adjustment. Screw terminals provide secure connections for input and output wiring.

Suitable for

• RGB and RGBW LED strip lighting
• Single-color LED strips or modules
• Indoor decorative and accent lighting
• Commercial display and cove lighting

Key specifications

• Output voltage: 12V DC
• Max output power: 100W
• Channels: 4
• Dimming: PWM 0-100%
• Input voltage: 200-240V AC, 50/60Hz
• IP rating: IP20
• Housing material: ABS plastic / metal enclosure

Recommendations

For indoor LED installations requiring multi-channel control and integrated power. Verify total LED load does not exceed 100W. Use appropriate gauge wiring for connections.
