SYNERGY21 S218207 cable de conexión de fibra óptica OS2 monomodo 9/125 µm LC/APC a LC/APC, 15 m, G.657.A2, amarillo, 2,2 mm, guía de tiro

Singlemode OS2 fiber patch cable with a 9/125µm core and G.657.A2 bend-insensitive fiber, terminated with LC/APC connectors on both ends. The 15-meter length and 2.2mm yellow jacket suit indoor installations where low insertion loss and high return loss are required.

Overview

This simplex patch cable uses LC/APC connectors with an angled polish to reduce back reflections. The G.657.A2 fiber allows tighter bends without significant signal degradation, and the integrated pulling aid simplifies routing through conduits and cable management.

What stands out

• LC/APC to LC/APC connectors for low-reflection connections
• G.657.A2 bend-insensitive fiber with a 7.5mm minimum bend radius
• Integrated pulling aid for easier installation
• Yellow 2.2mm jacket for quick identification of singlemode fiber

Technical details

• Fiber type: Singlemode OS2, 9/125µm
• Connectors: LC/APC to LC/APC
• Length: 15 meters
• Jacket diameter: 2.2mm
• Insertion loss: ≤ 0.3 dB
• Return loss: ≥ 60 dB
• Wavelengths: 1310nm, 1550nm
• Minimum bend radius: 7.5mm

Our verdict

A reliable singlemode patch cable for high-performance fiber links, with bend-insensitive fiber and a pulling aid that eases installation in tight spaces.
