Synergy 21 controlador LED EOS 10 ZigBee CC + fuente de alimentación 250-1000mA 50W

The Synergy 21 LED Controller EOS 10 is a high-performance ZigBee 3.0 constant current (CC) LED controller with an integrated power supply, designed for professional single-channel LED lighting control. It delivers a maximum output power of 50W and supports an adjustable output current range from 250 to 1000 mA, making it compatible with a wide variety of LED modules and fixtures.

Advantages

Seamless integration into ZigBee smart home ecosystems (e.g., Philips Hue, Amazon Echo Plus, Samsung SmartThings). Smooth PWM dimming from 0.1% to 100% with high efficiency (>85%). Built-in protection features ensure long-lasting operation.

Suitable for

• Single-color LED strips and modules requiring constant current drive
• Smart lighting retrofits in residential and commercial spaces
• ZigBee-based home automation projects

Key specifications

• Product Type: LED Controller
• Control Protocol: ZigBee 3.0
• Driver Type: Constant Current (CC)
• Output Current Range: 250 - 1000 mA (selectable via DIP switches)
• Maximum Output Power: 50 W
• Input Voltage: 200-240V AC
• Output Voltage Range: 9 - 48 V DC
• Dimming Method: PWM via ZigBee
• Dimming Range: 0.1 - 100%
• Number of Channels: 1
• Power Supply: Integrated
• Protection: Overload, Short Circuit, Over Temperature
• Operating Temperature: -20°C to +45°C
• Housing Material: Plastic
• Certifications: CE, RoHS
• Efficiency: >85%

Recommendations

For optimal performance, pair with a compatible ZigBee gateway. Ensure the total connected LED load does not exceed 50W and that the required current is within the adjustable range. Suitable for indoor use only.
