SYNERGY21 tira LED Flex 2835 - 120 WW Pixel DC24V WS2811 IP65

The SYNERGY21 LED Flex Strip 2835 is a high-performance, individually addressable LED strip designed for professional lighting applications. Featuring 120 SMD 2835 LEDs per meter with warm white color temperature (2700K-3000K) and WS2811 control IC, this strip delivers vibrant, pixel-level control. With an IP65 rating, it is dust-tight and protected against water jets, making it suitable for both indoor and outdoor use. The strip operates on DC 24V and consumes approximately 24W per meter, providing up to 2400 lumens per meter. It is dimmable via WS2811 controller and can be cut every 3 LEDs (approx. 2.5 cm).

Advantages

Individually addressable pixels allow for dynamic lighting effects. High brightness and efficiency with long lifespan over 50,000 hours. Flexible PCB with self-adhesive backing simplifies installation. IP65 coating ensures durability in challenging environments.

Suitable for

• Architectural lighting
• Stage and event lighting
• Signage and channel letters
• Ambient and accent lighting
• DIY projects and custom installations

Key specifications

• LED Type: SMD 2835
• LED Density: 120 LEDs per meter
• Color Temperature: Warm White (2700K-3000K)
• Control IC: WS2811 (Individually Addressable)
• Input Voltage: DC 24V
• Power Consumption: Approx. 24W per meter
• Luminous Flux: Approx. 2400 lm/m
• IP Rating: IP65
• Beam Angle: 120°
• Dimmability: Yes (via WS2811 controller)
• Cuttable Segments: Every 3 LEDs (approx. 2.5 cm)
• Number of Pixels: 40 pixels per meter (1 pixel = 3 LEDs)
• CRI: >80 Ra
• Operating Temperature: -20°C to +50°C
• Lifespan: >50,000 hours
• Mounting: Self-adhesive backing
• Strip Width: Approx. 10 mm
• Strip Thickness: Approx. 4-5 mm (with IP65 coating)
• Connectivity: 3-pin JST SM connector (typical)
• Material: Flexible PCB with silicone coating

Recommendations

For optimal performance, use with a compatible WS2811 controller and a 24V power supply. Ensure proper heat dissipation when mounting on non-flammable surfaces. Avoid bending the strip beyond its minimum bend radius.
