SYNERGY21 tira LED Flex 5050 - 30 RGB Pixel DC12V SM1703 IP20

The SYNERGY21 LED Flex Strip 5050 is a high-quality RGB pixel strip designed for vibrant lighting effects. With 30 individually addressable LEDs per meter and SM1703 IC control, it offers smooth color transitions and dynamic animations. Operating at DC 12V, this strip is ideal for indoor decorative lighting, signage, and accent lighting.

Advantages

Individually addressable RGB pixels allow for creative lighting patterns. Self-adhesive backing simplifies installation on clean surfaces. Cuttable every 3 LEDs (approx. 10 cm) for custom lengths. Dimmable with compatible controllers for adjustable brightness.

Suitable for

• Indoor decorative lighting
• Signage and channel letters
• Accent lighting for shelves, coves, and displays
• DIY projects and custom lighting installations

Key specifications

• LED Type: SMD 5050
• LED Color: RGB (Full Color)
• Operating Voltage: DC 12V
• LED Density: 30 LEDs/meter
• Control IC: SM1703
• Individually Addressable: Yes
• IP Rating: IP20 (Indoor use only)
• Beam Angle: 120°
• Power Consumption: ~7.2 W/m
• Max Current: ~0.6 A/m
• Cuttable Segments: Every 3 LEDs
• Backing: Self-adhesive
• Lifespan: >50,000 hours
• Operating Temperature: -20°C to +50°C
• Connectivity: 3-Pin JST SM Connector
• Dimmable: Yes (via compatible controller)
• Color Depth: 24-bit (16.7 Million Colors)
• Material: Flexible PCB
• Certifications: CE, RoHS

Recommendations

For best performance, use with a compatible RGB pixel controller and a suitable DC 12V power supply. Ensure proper ventilation and avoid exposure to moisture.
