Tannoy OCV 6 altavoz de techo coaxial de 6" blanco

The Tannoy OCV 6 is a high-performance 6-inch coaxial pendant loudspeaker designed for distributed audio applications where premium sound quality and discreet aesthetics are required. Engineered for suspended installation, this speaker delivers exceptional clarity and coverage for commercial environments such as retail spaces, restaurants, conference rooms, and houses of worship.

Advantages

Featuring a 6-inch (150 mm) low-frequency driver and a 0.75-inch (19 mm) high-frequency driver in a coaxial configuration, the OCV 6 provides a consistent 90° conical dispersion pattern for even sound coverage. The single-point suspension mounting system simplifies installation, while the IP44 rating ensures protection against dust and splashing water, making it suitable for covered outdoor areas. With a frequency response of 65 Hz to 22 kHz and a peak SPL of 114 dB, this speaker delivers full-range audio with impressive dynamics.

Suitable for

• Background music and paging in retail stores, restaurants, and hotels
• Sound reinforcement in conference rooms and lecture halls
• Distributed audio in houses of worship and public spaces
• Covered outdoor areas requiring weather-resistant speakers

Key specifications

• Speaker Type: Coaxial Pendant Loudspeaker
• Low Frequency Driver: 6 inch (150 mm)
• High Frequency Driver: 0.75 inch (19 mm)
• Frequency Response (-10 dB): 65 Hz - 22 kHz
• Power Handling (Program): 120 W
• Power Handling (Peak): 240 W
• Nominal Impedance: 8 Ohms
• Transformer Taps (100V): 60 W, 30 W, 15 W
• Transformer Taps (70V): 60 W, 30 W, 15 W, 7.5 W
• Sensitivity (1W/1m): 90 dB
• Maximum SPL (Peak): 114 dB
• Dispersion Angle: 90° Conical
• Crossover Frequency: 2.8 kHz
• Enclosure Material: ABS
• Grille Material: Powder Coated Perforated Steel
• IP Rating: IP44
• Mounting Type: Single Point Suspension
• Colour: White

Recommendations

For optimal performance, pair the Tannoy OCV 6 with a compatible amplifier capable of delivering the required power. Ensure the suspension point is rated for the speaker's weight and follow local safety codes for overhead installations. The white finish blends seamlessly with most ceiling environments.
