Tapa lateral de zócalo Rittal AX 2830.420 VE2, 200 mm de altura, 400 mm de profundidad, RAL 7035

The Rittal AX 2830.420 VE2 side plinth trim provides a 200 mm high plinth for AX enclosures with 400 mm depth, enhancing stability and cable entry. Made from sheet steel with a dip-primed, powder-coated finish in RAL 7035 light grey, it includes two side trims and assembly parts.

Overview

This side plinth element is designed for Rittal AX enclosures. It consists of two side trims that screw onto plinth corner pieces, forming a C-profile for structural integrity. The 200 mm height allows convenient cable access and improves enclosure aesthetics.

What stands out

• Compatible with Rittal AX enclosures, 400 mm depth
• Sheet steel construction with powder-coated RAL 7035 finish
• Includes 2 side trims and assembly parts
• Screw-fastened to plinth corner pieces for secure mounting

Technical details

• Product type: Side plinth trim
• Plinth height: 200 mm
• Enclosure depth compatibility: 400 mm
• Material: Sheet steel
• Surface finish: Dip-primed, powder-coated
• Color: RAL 7035 (light grey)
• Design: C-profile
• Weight per piece: 1.6 kg

Our verdict

A reliable plinth solution for Rittal AX enclosures, offering robust construction and a clean finish.
