Telegärtner Cable de red Cat.6A S/FTP, 3 m, LSZH, gris 100017394

Ethernet patch cable with Cat.6A performance for 10 Gigabit Ethernet, shielded S/FTP construction and LSZH jacket for safe use in public buildings. The cable is 3 m long and operates reliably in temperatures from -40 to 85 °C.

Advantages

Pairs in metal foil (PiMF) and overall braid shield minimise alien crosstalk, enabling full 10GBASE-T throughput up to 500 MHz. The halogen-free LSZH jacket emits low smoke and no corrosive gases in case of fire.

Suitable for

• 10 Gigabit Ethernet links in data centres and enterprise networks
• Industrial environments with wide temperature fluctuations
• Public buildings requiring LSZH cabling

Key specifications

• Category: Cat.6A (Class EA)
• Shielding: S/FTP (PiMF)
• Length: 3 m
• Connectors: RJ45 male to RJ45 male
• Conductor: stranded copper, T568B
• Data rate: up to 10 Gbps
• Bandwidth: up to 500 MHz
• Jacket: LSZH, grey
• Operating temperature: -40 to 85 °C
• Standards: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2

Recommendations

Verify that both connected devices support 10GBASE-T to achieve full speed. For permanent installation, use appropriate strain relief and avoid tight bends.
