Tilt Sentry Bar - Detección de inclinación 360° con Wi-Fi y Bluetooth, IP67, batería de 10.000 mAh

The Tilt Sentry Bar is a high-precision tilt detection device designed for industrial and commercial applications where monitoring orientation and movement is critical. Featuring a MEMS accelerometer with 360° detection range and configurable sensitivity from 0.5° to 10°, it provides reliable alerts via push notifications, email, or dry contact relay. With IP67 dust and water resistance, a durable anodized aluminum housing, and a long-lasting 10,000 mAh rechargeable battery, this device is built for harsh environments.

Advantages

• High-precision MEMS accelerometer for accurate tilt detection
• 360° detection range with configurable sensitivity (0.5° to 10°)
• Dual connectivity: Wi-Fi (2.4GHz) and Bluetooth 5.0
• Long battery life: up to 12 months on a single charge
• IP67 rated: dust and water resistant
• Rugged anodized aluminum alloy housing
• Multiple alert mechanisms: push notifications, email, dry contact relay
• On-device data logging for 30 days of event history
• Automatic and manual calibration modes
• AES-128 encryption for secure communication
• Smart home integration via IFTTT and REST API
• OTA firmware updates for future-proofing

Suitable for

• Industrial equipment tilt monitoring
• Construction and structural health monitoring
• Solar panel alignment and tracking
• Warehouse racking and shelving stability
• Marine and offshore platform monitoring
• Smart building and facility management

Key specifications

• Detection Technology: High-precision MEMS Accelerometer
• Tilt Detection Range: 360° (all axes)
• Detection Sensitivity: Configurable from 0.5° to 10°
• Wireless Connectivity: Wi-Fi (2.4GHz 802.11b/g/n) & Bluetooth 5.0
• Power Source: Integrated Rechargeable Lithium-ion Battery
• Battery Capacity: 10,000 mAh
• Battery Life: Up to 12 months (typical use)
• Charging Interface: USB-C
• Environmental Rating: IP67 Dust and Water Resistant
• Operating Temperature Range: -20°C to 60°C (-4°F to 140°F)
• Alert Mechanisms: Push Notifications, Email Alerts, Dry Contact Relay Output
• Mounting Type: Integrated Brackets (screw mount), Magnetic Base
• Housing Material: Durable Anodized Aluminum Alloy
• Mobile App Support: iOS & Android
• Data Logging: On-device storage for 30 days of event history
• Calibration: Automatic and Manual Calibration Modes
• Communication Security: AES-128 Encryption
• Smart Home Integration: IFTTT, REST API
• Status Indicators: Multi-color LED for power, connection, and alert status
• Firmware Update Method: Over-The-Air (OTA)

Recommendations

For optimal performance, mount the Tilt Sentry Bar on a stable surface using the integrated brackets or magnetic base. Ensure the device is within range of a 2.4GHz Wi-Fi network for full functionality. Regular calibration is recommended for critical applications.
