TMSS GERMANY Telemechanique Sensors Conector hembra M12 4 polos recto cable PUR, 10m, negro, IP67 XZCP1241L10

This M12 female connector with a 10-meter PUR cable stands out for its rugged IP67 sealing and wide -25 to 80 °C operating range, making it a dependable link for industrial sensor connections. The gold-plated contacts ensure reliable signal integrity even in demanding environments.

Highlights

• M12 female, 4-pin, straight orientation
• 10 m PUR cable, black, unshielded
• Rated 4 A, 250 V AC/DC
• IP67 protection
• Operating temperature: -25 to 80 °C
• Gold-plated contacts, screw-on locking

In daily use

The screw-on locking system provides a secure connection that resists vibration, while the PUR jacket withstands oils, coolants, and mechanical stress. The 0.34 mm² conductors (AWG 22) balance current capacity with flexibility for routing in tight spaces.

Full specifications

• Connector type: M12
• Connector gender: Female
• Connector orientation: Straight
• Number of pins: 4
• Cable length: 10 m
• Cable material: PUR (Polyurethane)
• Cable colour: Black
• Rated current: 4 A
• Rated voltage: 250 V AC/DC
• IP rating: IP67
• Operating temperature range: -25 to 80 °C
• Shielding: Unshielded
• Conductor cross-section: 0.34 mm² (AWG 22)
• Wiring configuration: 4-wire
• Product series: OsiSense XZ
• Locking system: Screw-on
• Contact plating: Gold
• Connector body material: TPU (Thermoplastic Polyurethane)
• Cable outer diameter: 4.8 mm
• Insulation resistance: > 1000 MΩ

Final note

Designed for sensor and actuator wiring in industrial automation, this cable assembly offers a reliable, ready-to-use connection without the need for field assembly.
