TMSS GERMANY Telemechanique Sensors Conector hembra M12 recto 4 polos cable PUR, 2 m, Negro XZCP1241L2

Industrial automation often demands reliable sensor connections that withstand harsh environments. The TMSS GERMANY XZCP1241L2 addresses this need with a pre-wired M12 female connector, eliminating the need for field assembly and ensuring consistent performance.

Who is it for

This cable is intended for system integrators, maintenance technicians, and machine builders who require a dependable connection for sensors and actuators in industrial settings. It suits applications where quick installation and resistance to oils and mechanical stress are essential.

Main features

• M12 female straight connector with 4 pins
• 2 m black PUR cable, highly resistant to abrasion and chemicals
• Gold-plated contacts for reliable signal transmission
• Rated for 250 V AC/DC and 4 A, suitable for many sensor types
• IP67 protection when mated, for use in demanding environments

Specifications

• Connector type: M12 female, straight
• Number of pins: 4
• Cable length: 2 m
• Cable material: PUR (Polyurethane)
• Cable colour: Black
• Rated current: 4 A
• Rated voltage: 250 V AC/DC
• Operating temperature: -25 to 80 °C
• Conductor cross-section: 0.34 mm² (22 AWG)
• Shielding: Unshielded

Tips

For best results, pair this cable with M12 male connectors that match the 4-pin A-coded standard. Ensure the mating connector is properly tightened to maintain the IP67 seal. Avoid bending the cable sharply near the connector to prolong its life.
