Toshiba B8530220SW1 - 22 cm - 300 m

For high-volume Toshiba TEC thermal printers, the B8530220SW1 wax ribbon delivers a dependable black image at a width that matches full-size label formats. Unlike narrow ribbons that force multiple passes or leave unprinted margins, this 220 mm roll covers the entire print head in one pass, reducing waste and simplifying changeovers. The standard wax formulation is tuned for coated and uncoated paper stocks, making it a practical choice for shipping, warehouse, and retail label runs where clarity and cost per label matter most.

Highlights

• 220 mm width fits Toshiba B-852, B-853, B-SX8T, and B-EX4T2 industrial printers
• 300 m length minimizes roll changes during long batch jobs
• Standard wax ink offers solid black density on paper and tag stock
• 1-inch cardboard core for quick, secure mounting
• Ink side outside for correct orientation in most Toshiba mechanisms

In daily use

This ribbon is engineered for straightforward thermal transfer printing. It performs best with coated or uncoated paper labels, inventory tags, and general-purpose barcode media. The wax formulation provides moderate smudge and scratch resistance, suitable for labels that are handled but not exposed to harsh abrasion or chemicals. At speeds up to 10 inches per second, the B8530220SW1 keeps pace with high-throughput operations, producing crisp barcodes and legible text without excessive print head energy. The wide format is especially useful for shipping labels, pallet tags, and large retail price tags that require edge-to-edge coverage.

Full specifications

• Brand: Toshiba
• Model: B8530220SW1
• MPN: B8530220SW1
• Ribbon type: Thermal transfer wax
• Ribbon colour: Black
• Ribbon width: 220 mm
• Ribbon length: 300 m
• Core diameter: 1 inch (25.4 mm)
• Core material: Cardboard
• Ink side: Outside
• Print technology: Thermal transfer
• Compatible brands: Toshiba
• Compatible printer series: B-852, B-853, B-SX8T, B-EX4T2
• Recommended media: Coated paper, uncoated paper, tag stock, synthetic paper
• Maximum print speed: 10 IPS (inches per second)
• Smudge resistance: Moderate
• Scratch resistance: Moderate
• Operating temperature: 5°C to 35°C (41°F to 95°F)
• Storage temperature: -5°C to 40°C (23°F to 104°F)
• Operating humidity: 30% to 85% RH non-condensing
• Storage humidity: 20% to 80% RH non-condensing
• Applications: Shipping labels, inventory labels, retail tags, general-purpose barcode labels, logistics

Final note

The B8530220SW1 is a straightforward, high-coverage wax ribbon for Toshiba industrial printers. Its 220 mm width and 300 m length make it a workhorse for label-intensive environments where consistent black output and minimal downtime are essential.
