Toshiba MG11ACA14TE Enterprise Capacity HDD 14TB 3,5" SATA 7200rpm 512MB CMR

The Toshiba MG11ACA14TE is a 14TB enterprise-class 3.5-inch hard disk drive from the Toshiba MG Series, engineered for demanding 24/7 data centre, cloud storage, and server workloads. Built with helium-sealed technology, CMR (Conventional Magnetic Recording) with 9 platters and 18 heads, and a 512MB cache buffer, this drive delivers sustained transfer rates of up to 260 MiB/s over the SATA 6Gb/s interface, making it one of the highest-capacity SATA enterprise HDDs in its class.

Advantages

The MG11ACA14TE is rated for an impressive 550TB/year workload, backed by a 2.5-million-hour MTBF rating and a non-recoverable read error rate of 1 per 10^15 bits, ensuring exceptional reliability for mission-critical storage applications. The helium fill reduces internal turbulence and power consumption, achieving an operating power draw of just 8.0W while maintaining 7200 RPM spindle speed for consistent high throughput. Advanced features including Native Command Queuing (NCQ), rotational vibration compensation, and 512e sector emulation make it compatible with modern storage platforms and RAID configurations.

Suitable for

• Data centre operators requiring high-capacity, reliable bulk storage at scale
• Cloud service providers and large enterprise NAS/SAN deployments
• Server administrators building high-density RAID arrays for backup, archiving, or primary storage

Key specifications

• Brand: Toshiba
• Model: MG11ACA14TE
• Series: MG11 Enterprise Capacity
• Capacity: 14 TB
• Form Factor: 3.5 inch
• Interface: SATA 6Gb/s (SATA III)
• Spindle Speed: 7200 RPM
• Cache Buffer: 512 MB
• Sustained Data Transfer Rate: Up to 260 MiB/s
• Recording Technology: CMR (Conventional Magnetic Recording)
• Sector Technology: 512e (Advanced Format)
• Helium Sealed: Yes
• Platters / Heads: 9 / 18
• Workload Rating: 550 TB/year
• MTBF: 2,500,000 hours
• Non-Recoverable Read Errors: 1 per 10^15 bits
• Power (Operating): 8.0 W
• Power (Idle): 5.0 W
• Operating Temperature: 5 to 60 °C
• Weight: 0.77 kg

How to use

Install the MG11ACA14TE into a 3.5-inch drive bay in a server, NAS enclosure, or desktop workstation. Connect via a standard SATA III data cable and power connector. For RAID configurations, pair multiple drives for redundancy and performance. Ensure the host system BIOS or RAID controller supports 512e sector addressing for full compatibility.

Recommendations

The Toshiba MG11ACA14TE is an outstanding choice for organisations building cost-effective, high-density SATA storage infrastructure — its 550TB/year workload rating and 2.5-million-hour MTBF make it one of the most reliable and durable enterprise SATA HDDs available at the 14TB capacity point.
