Transceptor BlueOptics QSFP28 100GBASE-LR4 compatible con Finisar FTL4C1QL1L (BO25K13602D)

The BlueOptics BO25K13602D is a high-performance QSFP28 transceiver designed for 100 Gigabit Ethernet applications. It is fully compatible with the Finisar FTL4C1QL1L and offers reliable, cost-effective connectivity for data center and enterprise networks. This transceiver supports 100GBASE-LR4 standard over single-mode fiber, enabling distances up to 10 km.

Advantages

This BlueOptics transceiver provides a cost-effective alternative to OEM modules without compromising performance or reliability. It is hot-pluggable, supports Digital Diagnostic Monitoring (DDM/DOM), and is compliant with industry standards such as IEEE 802.3ba and SFF-8665. The module is built with high-quality components for long-term durability.

Suitable for

• Data center interconnects
• Enterprise networking
• High-performance computing
• Telecommunications

Key specifications

• Form Factor: QSFP28
• Data Rate: 100 Gbps
• Ethernet Standard: 100GBASE-LR4
• Max Distance: 10 km
• Fiber Type: Single-Mode Fiber (SMF)
• Connector Type: Duplex LC
• Wavelengths: 1295.56 nm, 1300.05 nm, 1304.58 nm, 1309.14 nm
• DDM/DOM Support: Yes
• Power Consumption: Max 4.5 W
• Operating Temperature: 0°C to 70°C
• Compatibility: Finisar FTL4C1QL1L and multi-vendor (Cisco, Juniper, HP, Arista)
• Transmitter Type: DFB Laser
• Receiver Type: PIN Photo Detector
• Hot Swappable: Yes
• Compliance: IEEE 802.3ba, SFF-8665, SFF-8636, RoHS
• Voltage: 3.3 V

Recommendations

For optimal performance, use with OS2 single-mode fiber patch cables. Ensure your switch or router supports QSFP28 modules and 100GBASE-LR4 standard.
