TSC módulo de cabezal de impresión TTP-246M Pro

With a resolution of 203 dpi and 832 total print elements, this TSC print head module delivers crisp, high-contrast barcodes and text on labels up to 104 mm wide. Engineered for the TTP-246M Pro, it is a direct replacement that restores original print quality in minutes.

Overview

The TSC 98-0470022-00LF is a field-replaceable thermal print head module designed for TSC TTP-246M Pro, TTP-246M Plus, and TTP-246M industrial barcode printers. It supports both direct thermal and thermal transfer printing, making it suitable for a wide range of label materials including paper, polyester, and polypropylene. The ceramic substrate ensures long life and consistent heat distribution across the entire 4.09-inch (104 mm) print width.

What stands out

• 203 dpi resolution with 8 dots/mm for sharp, scannable barcodes
• 832 print elements covering a max print width of 104 mm
• Thin film thermal technology for fast heat-up and precise energy control
• FPC connector for simple, tool-free installation
• Genuine TSC replacement part — guaranteed compatibility and performance

Technical details

• Printer compatibility: TSC TTP-246M Pro, TTP-246M Plus, TTP-246M
• Print resolution: 203 dpi (8 dots/mm)
• Print technology: Direct thermal and thermal transfer
• Maximum print width: 4.09 inches (104 mm)
• Print head type: Thin film thermal print head
• Total print elements: 832 dots
• Substrate material: Ceramic
• Connector interface: FPC (Flexible Printed Circuit)
• Part type: Replacement module
• Condition: New
• Manufacturer: TSC Auto ID Technology Co., Ltd.
• Application: Industrial barcode label printers
• Installation: Field replaceable unit (FRU)

Our verdict

When print quality starts to fade, this genuine TSC print head module is the fastest way to bring your TTP-246M Pro back to factory performance. Its ceramic construction and precise thin-film technology ensure reliable, high-resolution output for thousands of labels.
