tvONE Magenta Research MG-DA-614 amplificador de distribución DVI-D 1x4

The tvONE Magenta Research MG-DA-614 is a high-performance DVI-D distribution amplifier designed to split a single DVI-D signal to four identical outputs. Ideal for digital signage, broadcast, and professional AV installations, this unit ensures signal integrity over long distances with built-in cable equalization up to 15 meters at WUXGA resolution. With support for HDCP and EDID pass-through, it guarantees compatibility with a wide range of sources and displays.

Advantages

• Maintains signal quality with cable equalization up to 15m at 1920x1200
• HDCP compliant for protected content distribution
• EDID pass-through ensures seamless handshake between source and displays
• Compact metal chassis for durability and rack-mountable with optional kit
• Low power consumption (<5W) with external 5V DC supply

Suitable for

• Digital signage systems requiring multiple displays
• Broadcast and production environments
• Conference rooms and lecture halls
• Retail and hospitality AV installations

Key specifications

• Product Type: DVI-D Distribution Amplifier
• Input: 1 x DVI-D (Female)
• Output: 4 x DVI-D (Female)
• Video Standard: DVI-D Single Link
• Max Resolution: 1920 x 1200 @ 60Hz / 1080p
• Max Pixel Clock: 165 MHz
• Max Data Rate: 1.65 Gbps per TMDS link
• HDCP Support: Yes
• EDID Management: EDID Pass-through
• Cable Equalization: Up to 15m (50ft) at WUXGA
• Power Supply: External 5V DC
• Power Consumption: < 5W
• Indicators: Power LED, Input/Output Status LEDs
• Chassis Material: Metal
• Mounting: Desktop, Rack-mountable (optional kit)
• Operating Temperature: 0°C to 40°C
• Relative Humidity: 10% to 90% non-condensing
• Compliance: CE, FCC, RoHS

Recommendations

For optimal performance, use high-quality DVI-D cables and ensure proper ventilation. The optional rack-mount kit is recommended for permanent installations.
