Uni-T UTD2202CEX+ Osciloscopio digital 200 MHz 2 canales

The Uni-T UTD2202CEX+ is a high-performance digital oscilloscope designed for professional engineers and technicians. With a bandwidth of 200 MHz and a real-time sample rate of 1 GS/s, it delivers accurate waveform capture and analysis. The 8-inch TFT LCD display with 800x480 resolution provides clear visualization of signals.

Advantages

This oscilloscope features a memory depth of 64 Mpts, allowing extended waveform recording. The high waveform capture rate of 80,000 wfms/s ensures reliable detection of rare events. It supports multiple trigger types and automatic measurements for efficient troubleshooting.

Suitable for

• Electronic circuit design and debugging
• Educational laboratories
• Service and repair workshops
• Embedded system development

Key specifications

• Bandwidth: 200 MHz
• Analog Channels: 2
• Real-time Sample Rate: 1 GS/s
• Memory Depth: 64 Mpts
• Display: 8-inch TFT LCD (800x480)
• Vertical Sensitivity: 1 mV/div - 20 V/div
• Time Base Range: 2 ns/div - 50 s/div
• Waveform Capture Rate: 80,000 wfms/s
• Input Impedance: 1 MΩ || 18 pF
• Max Input Voltage: 400 V (DC+AC Peak)
• Trigger Types: Edge, Pulse, Video, Slope, Alternate, Runt, Logic, Nth Edge, Delay, Setup/Hold, Rise/Fall Time, Window, Pattern, Duration
• Automatic Measurements: 34 types
• Interface: USB Host, USB Device, LAN
• Serial Bus Decoding: I2C, SPI, RS232/UART, CAN, LIN (Standard)
• FFT: Yes
• Vertical Resolution: 8-bit
• Power Supply: 100-240V AC, 50/60Hz

Recommendations

For optimal performance, use the included probes and accessories. This oscilloscope is ideal for professionals requiring precise signal analysis in a compact form factor.
